Filter press is a kind of mechanical equipment which uses a special filter medium to exert a certain pressure on the object to make the liquid permeate out. It is a common solid-liquid separation equipment. It is used in chemical, pharmaceutical, metallurgy, dyestuff, food, brewing, ceramics, environmental protection and other industries.

Inquire Now Next Product

Description

Introduction of Filter Press

Working principle

The feed enters the press at the corner of the plate,using a pump suitable for pumping up to 80-90 psi. Then, the feed travels the path of least resistance (up between the filter plates), which has filter media inserted between the plates, and the void between the plates is filled with the slurry, as the liquid passes through the filter media, and travels up to the outlet port at the top of the plate. This liquid is referred to as the "filtrate", and is discharged from the press. The solids remain in the void between the plates, until the plates discharge the filtered solids.

Waste Management Machinery Filter Press For Industrial Wastewater Treatment

Application scope of Filter Press Machine

Filter Press Machine are widely applied in various kinds of solid-liquid procession, such as petroleum, chemical, metallurgy, environmental protection, food, beverage, pharmaceutical, sugar, starch, paper, coal washing, ceramics, mineral processing, and many other industries

Waste Management Machinery Filter Press For Industrial Wastewater Treatment

Hydraulic Filter Press Technical Data

Model	Filter area(m2)	Plate size(mm)	Cake thickness(mm)	Filter chamber volume(L)	Number of filter plate(PCS)	Pressure(Mpa)	Weight (kg)	Dimension(LWH)(mm)
XY/520-25U	4	520*520	25	40	9	0.5-1.5	560	1915700860
	6			60	14		630	2145700860
	8			80	19		700	2375700860
	12			120	29		830	2835700860
	16			160	39		980	3295700860
	18			176	44		1160	3525700860
	20			200	49		1360	3755700860
XY/700-25U	20	700*700	25	250	24	0.5-1.5	2210	312011001100
	30			380	37		2660	378511001100
	40			500	49		3080	439511001100
XY/800-30U	30	800*800	30	480	29	0.5-1.5	2080	365012001160
	40			640	39		2380	421012001160
	50			800	49		2700	477012001160
	60			960	59		3060	533012001160
XY/870-30U	50	870*870	30	760	37	0.5-1.5	3580	422013001250
	60			920	45		3980	471013001250
	70			1080	53		4500	520013001250
	80			1200	59		5200	556013001250
XY/1000-30U	80	1000*1000	30	1303	46	0.5-1.5	3470	516015001350
	90			1468	52		4040	552515001350
	100			1635	58		4360	589015001350
	120			1966	70		4960	662015001350
XY/1250-30U	120	1250*1250	30	1800	44	0.5-1.5	6600	541017501600
	140			2120	52		7200	594017501600
	150			2280	56		7500	620017501600
	160			2400	59		7750	640017501600
	180			2720	67		8500	723017501600
	200			3000	74		9000	769017501600
	250			3800	93		10500	901517501600
