Hydraulic oil press machine is designed for making oil with rich-oil seeds, raw materials such as coconut, avocado, olive, sesame, peanut, palm, rapeseed, sunflower, etc.
Introduction
Hydraulic oil press machine is designed for making oil with rich-oil seeds, raw materials such as coconut, avocado, olive, sesame, peanut, palm, rapeseed, sunflower, etc.
Application
Hydraulic oil press machine is designed for making oil with rich-oil seeds, raw materials such as coconut, avocado, olive, sesame, peanut, palm, rapeseed, sunflower, etc.
Technical Parameter
| Model | GYP50 | GYP100 | GYP150 | GYP200 | GY300 | GYP400 | GYP500 |
| Capacity (L/H) | 100 | 200 | 300 | 500 | 600 | 900 | 1200 |
| Inner barrel size (mm) | Φ400*500 | Φ500*500 | Φ550*600 | Φ600*700 | Φ700*750 | Φ800*800 | Φ800*900 |
| Press time (min) | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Motor power (kw) | 3 | 3 | 3 | 4 | 4 | 4-22 | 4-22 |
| Cylinder maximum pressure (ton) | 30 | 30 | 30-50 | 50-500 | 50-500 | 50-500 | 50-500 |
| Dimension(L*W*H) | 1200*650*1760 | 1300*740*1800 | 1550*780*1970 | 1600*890*2170 | 1650*945*2270 | 1750*1000*2370 | 1950*1050*2580 |
| Weight (kg) | 380 | 400 | 500 | 600 | 800 | 900 | 950 |
