PGZ 1600 Scraper Bottom Discharge Centrifuge Hemp Oil Liquid Solid Separator
  • PGZ 1600 Scraper Bottom Discharge Centrifuge Hemp Oil Liquid Solid Separator
PGZ 1600 Scraper Bottom Discharge Centrifuge Hemp Oil Liquid Solid Separator PGZ 1600 Scraper Bottom Discharge Centrifuge Hemp Oil Liquid Solid Separator

PGZ 1600 Scraper Bottom Discharge Centrifuge Hemp Oil Liquid Solid Separator

PGZ 1600 Scraper Bottom Discharge Centrifuge is applied for fine and medium grain solid particle suspension separation, the solid particle could be granule, crystal or fiber type. Especially for the separation which the material has high viscosity, fine grain, poisonous and inflammable.

Share
Description

Description:

PGZ 1600 Scraper Bottom Discharge Centrifuge is applied for fine and medium grain solid particle suspension separation, the solid particle could be granule, crystal or fiber type. Especially for the separation which the material has high viscosity, fine grain, poisonous and inflammable. Widely used in the area of chemical, pharmaceutical, food, light industry, environment protection etc.

PGZ 1600 Scraper Bottom Discharge Centrifuge Hemp Oil Liquid Solid Separator

Main Features:

1.Closed structure, achieve the purpose of sealing explosion-proof, suitable for the application in poisonous, inflammable, explosive places.

2.Controlled by PLC, use inverting speed regulator and braking resistor, combined with hydraulic and pneumatic devices, to achieve manual or automatic operation.

3.With various protection functions, achieve full automatic of start, feeding, dewatering, washing, discharging, unmanned operation. It can clean from all angles, safe and stable, meet GMP standard.

4.Hydraulic scraper discharging system, it is a design of stainless steel closed hydraulic oil cylinder, which can contact the material directly.

PGZ 1600 Scraper Bottom Discharge Centrifuge Hemp Oil Liquid Solid Separator

Applications:

Apply to separating the suspension containing particles, but also fibers, especially the highly sticky, containing micro particles, poisonous and flammable materials, like antibiotics, vitamins, and minerals, salts, gourmet powders, foodstuff additives, amylum, sugar, chemical flavors, thiamin, plasters, Glauber's salt, bluestone, potassium chloride, borax, dyestuffs, pigment, resin, pesticides, and environmental protection. The centrifuge is highly automated, has large capacity and can be remote-controlled.

Technical Parameters:

ModelPGZ800PGZ1000PGZ1250PGZ1600
  BowlDiameterKg800100012501600
Effective volumeL115175300775
Loading limitKg155250350800
Rotating speedr/min12001000950650
Separating factorω2r/g1007805700572
Motor powerkw7.51518.537
Dimension(L×W×H)mm1850×1450×20502000×1550×21502260×1800×22003300×2300×3100
Weightkg2500350050008500
