Screw conveyor is used to transport powder or small free flow products from low position to high place. such as coal, cement, agriculture, metallurgy, chemical, food and so on. It is not suitable to transport perishable materials and materials having big viscosity.
Product Description:
Screw conveyor is used to transport powder or small free flow products from low position to high place. such as coal, cement, agriculture, metallurgy, chemical, food and so on. It is not suitable to transport perishable materials and materials having big viscosity.
Main Features:
1. Installation, removal and maintenance is very convenient
2. Bearing is sealed good
3. Won't blocking materials when transporting.
4. Simple structure, small size, it occupied area and the space is small
5. It can have more than one inlet and outlet.
6. Safe and reliable operation, it can complete conveying, mixing, stirring, loose and other technology at the same time.
Product Application:
Applicable to various industries, such as building materials, chemical industry, electric power, metallurgy, coal, food and other industries, applicable to horizontal or oblique conveying powder, granulated and small lump materials, such as coal, ash, slag, cement, food, etc.
Technical Parameters:
| Pipe diameter | mm | 108 | 133 | 159 | 168 | 219 | 273 | 325 | 356 | 426 |
| Spiral diameter | mm | 90 | 115 | 140 | 150 | 200 | 250 | 300 | 330 | 400 |
| Screw-pitch | mm | 90 | 115 | 140 | 150 | 200 | 250 | 300 | 330 | 350 |
| Rotate speed | r/min | 186.7 | 140 | 140 | 140 | 93.3 | 88 | 88 | 88 | 65 |
| Capacity | m3/h | 2 | 3 | 5.5 | 6.5 | 11 | 20 | 33 | 44 | 50 |
