Electric Power 3KW To 120KW Small Industrial Electric Steam Generator
  • Electric Power 3KW To 120KW Small Industrial Electric Steam Generator
Electric Power 3KW To 120KW Small Industrial Electric Steam Generator Electric Power 3KW To 120KW Small Industrial Electric Steam Generator

Electric Power 3KW To 120KW Small Industrial Electric Steam Generator

LDR electric heating series fast steam generator is a kind of small vertical automatic heating equipment. It can generate steam quickly (about 3~5 minutes) and has high thermal efficiency.

Share
Description

Introduction:

LDR electric heating series fast steam generator is a kind of small vertical automatic heating equipment. It can generate steam quickly (about 3 ~ 5 minutes) and has high thermal efficiency. It has a vertical pipe structure, small water volume, safety and no need of annual inspection. The whole set of equipment can generate steam only by connecting water source and power supply.

Electric Power 3KW To 120KW Small Industrial Electric Steam Generator

Product Features:

1. Small water capacity, fast water vapor speed, sufficient steam production and high efficiency;

2. The one-button operation of microcomputer can install water and electricity in place and press the button to open the generator. The generator will enter the automatic operation state, which is safe and simple.

3. The single power can be adjusted, and the operating load of the equipment can be adjusted according to the steam consumption, which is more energy-saving.

4. The product is equipped with high-quality pressure controller, safety valve, with overpressure, low water level, overheating protection and leakage protection multiple protection, to ensure product quality and use safety;

5. The whole machine factory, has been equipped with water pump, solenoid valve and one-way valve, only need to connect the power supply, steam pipe, water inlet and sewage pipe, save the installation cost and a lot of installation materials;

6. Reasonable and scientific product structure design, small size, convenient installation and flexible movement.

Electric Power 3KW To 120KW Small Industrial Electric Steam Generator

Application range: Small power electric steam generators are widely used in food and beverage catering industry, clothing ironing and washing industry, concrete and cement curing industry, electroplating pickling industry, chemical explosion-proof industry, rubber vulcanization industry, medical and pharmaceutical industry, casting dewaxing industry, Chinese medicine decoction pieces production industry, bathing and swimming industry, biological fermentation industry and experimental research industries, can also be used with production line machinery and equipment.

Electric Power 3KW To 120KW Small Industrial Electric Steam Generator

Technical Parameters:

PowerRated EvaporationMax PressureMax TemperatureRated CurrentThermal efficiencySize (MM)Weight (KG)
3KW4kg/h0.4/0.7Mpa151/171℃6A99%680*520*85050
6KW8kg/h0.4/0.7Mpa151/171℃9A99%750*550*92075
9KW12kg/h0.4/0.7Mpa151/171℃14A99%750*550*92079
12KW16kg/h0.4/0.7Mpa151/171℃18A99%750*550*92085
18KW24kg/h0.4/0.7Mpa151/171℃27A99%850*600*100092
24KW32kg/h0.4/0.7Mpa151/171℃41A99%850*600*1000118
36KW50kg/h0.4/0.7Mpa151/171℃55A99%900*650*1150132
48KW65kg/h0.4/0.7Mpa151/171℃70A99%900*650*1200150
60KW80kg/h0.4/0.7Mpa151/171℃79A99%900*650*1200150
72KW100kg/h0.4/0.7Mpa151/171℃113A99%800*870*1300280
96KW132kg/h0.4/0.7Mpa151/171℃146A99%1010*740*1210280
108KW150kg/h0.4/0.7Mpa151/171℃164A99%1010*740*1210300
120KW170kg/h0.4/0.7Mpa151/171℃183A99%1010*740*1210300
